• Exclusive 8 charactor Alfanumaric dot-matrix digital type display for Menu setting.
  • Five Metric & Five Inch Measuring ranges.
  • 101 Segment, 3 Colour LED Bar- graph Column type measurement display.
  • Column can be configured to originate from the centre or one end of scale.
  • 8-character Alfanumaric dot-matrix digital type display shows. measurements either in Absolute or Comparative form.
Technical Data Sheet
Metric Ranges Resolutions Inch Ranges Resolutions
±10, ±30, ±100,.±300 and ±1000 microns 0.2, I, 2, 10 and 20 microns ±0.0003, ±0.001, ±0.003, ±0.01 and ± 0.03 inch 0.00001, 0.00002, 0.0001, 0.0002 and 0.001 inch
